PS Audio BHK Signature Pre Amplifier

PS Audio BHK Signature Preamplifier

State of the Audio Art in musical pre-amplification

Introducing one of the most remarkable musical instruments in the world, the BHK Signature Preamplifier. This exceptionally built vacuum tube preamplifier opens up the music and reveals nuances, life and space not previously heard on your system. It is the perfect interface between your sources and power amplifier.

Designed by Bascom H. King, the BHK Signature distils Bascom’s 50 plus years of high-end audio design experience into a single masterpiece of audio amplification. “This is the best sounding preamplifier I have ever designed or heard,” and that’s saying a lot for a man of Bascom’s experience. Preamplifiers play a critical role in any separates audio system, strategically positioned between sources of music: CD players, phono preamps, DACs, tape recorders and tuners – and your power amplifier – the preamp serves essential roles of control and isolation.

Control is simple in concept, but extraordinarily difficult to design in an acoustically transparent manner. Control duties such as input switching, volume, balance, and amplification can place unwanted acoustic thumbprints on the music if not designed with extraordinary care. The challenge in any design is to do as little damage to music’s purity as possible. Details on how each section of the BHK Signature executes control with minimal sonic impact can be found in the Overview section on this page.

• Zero-loss vacuum tube input stage
• User accessible switch allows both 12 volt and 6 volt tubes to be used
• Differentially coupled balanced MOSFET output stage
• All through hole construction (no surface mount parts)
• PRP resistors in signal path
• 5 RCA Single ended inputs
• 5 XLR balanced inputs
• Single ended and balanced outputs
• Single ended and balanced outputs can be used together or separate
• Fully balanced input to output
• High current oversized power transformer
• Fully regulated power supplies using BHK designed MOSFET discrete voltage regulators
• Full BHK designed zero feedback, discrete MOSFET headphone stage
• Remote control
• Front panel standby button for vacuum tube stage
• -3dB greater than 200kHz
• Volume and balance through a revolutionary new combination of gain and attenuation control
• Two output DC control triggers
• Easy access to tubes if you want to roll with different ones
• Each input can be configured as a HT bypass

Physical
Unit Weight: 22 lbs [13.5 kg]
Unit Dimensions: 14” x 17” x 4” [ 36cm x 43cm x 10cm]
Shipping Weight: 31 lbs [19 kg]
Shipping Dimensions: 20.5”x 24” x 10” [52cm x 61cm x 25cm]

Power requirements
Input Power: Model specific 100VAC, 120VAC, or 230VAC 50 or 60Hz
Power Consumption: 60W

Audio inputs
Coaxial RCA single ended: 5
XLR Balanced: 5
Input Impedance: 33KΩ minimum
Unbalanced (RCA): 66KΩ minimum
Balanced (XLR)
Sensitivity: Unbalanced 1.3V/33KΩ, Balanced 1.3V/66KΩ

Audio Outputs
Coaxial RCA single ended: 2
XLR Balanced: 2

Analog Audio Output
Output level: 4.0 Vrms
Output Impedance: <100Ω
Frequency Response: +/- 0.1dB, 20-20KHz
THD&IM @ 1KHz (full scale): <0.03%
Bandwidth: -3dB 0.1Hz - 200kHz

DC Triggers
+12V: 2

Headphone Performance
Output Power:  >200mW
300Ω:  4.0 Watts
16Ω
S/N Ratio: >90dB (1KHz)
THD & IM 1 volt out: <0.02%
Output Impedance: <0.5Ω
